4.5 CALIBRATE
Note: Turbidity measurement has been calibrated by the manufacturer — it does not need to be
calibrated again.
Note: It is imperative to calibrate for solid matter measurement (refer to section
The zero point for turbidity and solid matter measurement has been set in the sensors by
the manufacturer.
Installation conditions in the pipes can cause interfering ground reflection when
measuring turbidity, which in turn may cause the zero point to shift. Compensate for this
effect with an offset correction (section
). If there are deviations between
the displayed measurement values and laboratory results that are unrelated to the factors
described above, the slope of the calibration curve can be adjusted using a factor (refer
to section
4.5.1 Calibration of the TURBIDITY (TRB) parameter
PROBE INFO
SENSOR NAME
Device name
EDITED NAME
INSTRUMENT
NUMBER
TURBIDITY
0.001 to 9999 FNU
SOLID
0.001 to 500 g/L
MODEL NUMBER
Sensor item number
CODE VERSION
Sensor software
COUNTER
MANUAL RESET PRESS ENTER: Security prompt
TEST / MAINT: COUNTER X DAYS BACKWARDS,
TOTAL: OPERATING HOURS COUNTER,
INTERVAL
Default for maintenance counter
SERVICE
SIGNALS
Explanation: refer to service manual
S5E1
S5E3
S6E1
S6E3
S5E2
S5E4
S6E2
S6E4
OUTPUT MODE
Behavior of instrument outputs in the SERVICE menu
HOLD
ACTIVE
TRANSFER
SELECTION
Service access
4.4.2 SENSOR setup
SELECT SENSOR (if there is more than one sensor)
