27
Section 7
Replacement parts and accessories
7.1 Replacement parts
Description
Catalog number
Manual (xx = language code)
DOC023.xx.90171
7.2 Accessories
Description
Catalog number
Silicone gasket for TriClamp fitting
LZY653
PTFE gasket for TriClamp fitting
LZY654
FKM Gasket for TriClamp fitting
LZY655
2-piece clip with thumb screw for TriClamp fitting
LZY656
3-piece clip with thumb screw for TriClamp fitting (for use with PTFE gasket)
LZY657
Sensor bracket including 90 ° adapter
LZX414.00.10000
Consisting of:
Base
ATS010
Mounting plate
HPL061
Holding clamp (2×)
LZX200
Assembly pipe 2 m (6 ft)
BRO075
HS small parts set
LZX416
1.8 m (5.9 ft) extension pipe
LZY414
1.0 m (3 ft) extension pipe
LZY413
Second attachment point (including holding clamp)
LZX456
90 ° sensor adapter
AHA034
Set of small parts for securing sensor
LZX417
90 ° base
ATS011
Retractable ball valve fitting for TSS EX1 sc TriClamp sensor
LZU301.99.00000
Built in safety valve for TSS EX1 sc, 6 bar, with stainless steel flange
LZY630.00.20000
Built in safety valve for TSS EX1 sc, 6 bar, with carbon steel flange
LZY630.00.21000
Built in safety valve for TSS EX1 sc, 6 bar, without flange
LZY630.00.22000
sc sensor plug
LZX971
Terminal box LZY586
LZY586
Band clamp for grounding of explosion-proof probes
LZI12020
