Cashco Premier - Manual (Page 4)

IOM-148 4
Valve Body Size Actuator
Model
No.*
Failure
Action
Benchset Range Supply Pressure Qty of
Range
Springs
in. (DN) psig (Barg) psig (Barg)
1”, 1-1/2” & 2” (25, 40 & 50)
48R-01 ATO-FC
5-15 (.34-1.03) 20 (1.4) 6
48D-01 ATC-FO
3” & 4” (80 & 100)
148R-01 ATO-FC
5-13 (.34-.90) 20 (1.4) 4
148D-01 ATC-FO
4”, 6’ & 8” (100, 150, & 200)
148R-02 ATO-FC
10-26 (.69-1.79) 36 (2.5) 8
148D-02 ATC-FO
*Model 48 included for clarity
TABLE 2
RANGER QCT
ACTUATOR BENCHSET RANGES
Valve Body Size Actuator
Model
No.*
Failure
Action
Benchset Range Supply Pressure Qty of
Range
Springs
in. (DN) psig (Barg) psig (Barg)
3” & 4” (80 & 100)
48R-01 ATO-FC
5-15 (.34-1.03) 20 (1.4) 6
48D-01 ATC-FO
6” (150)
148R-01 ATO-FC
5-13 (.34-.90) 20 (1.4) 4
148D-01 ATC-FO
8” (200)
148R-03 ATO-FC
7.5-19.5 (.52-1.34) 27 (1.9) 6
148D-03 ATC-FO
10” (250)
148R-02 ATO-FC
10-26 (.69-1.79) 30 (2.1) 8
148D-02 ATC-FO
*Model 48 included for clarity
TABLE 3
PREMIER EZO
ACTUATOR BENCHSET RANGES
Valve Body Size Actuator
Model
No.*
Failure
Action
Benchset Range Supply Pressure Qty of
Range
Springs
in. (DN) psig (Barg) psig (Barg)
3” & 4” (80 & 100)
48R-01 ATO-FC
5-15 (.34-1.03) 20 (1.4) 6
48D-01 ATC-FO
6” (150)
148R-01 ATO-FC
5-13 (.34-.90) 20 (1.4) 4
148D-01 ATC-FO
8” & 10” (200 & 250)
148R-03 ATO-FC
7.5-19.5 (.52-1.34) 27 (1.9) 6
148D-03 ATC-FO
*Model 48 included for clarity
TABLE 4
PREMIER UNLINED
ACTUATOR BENCHSET RANGES
