ENGLISH

Legend of symbols

Intended use

Description

Intended use and limits to use

Technical data

Limits to use

This symbol shows parts which must be read with care.

This symbol means the parts which describe safety issues.

This symbol tells you what to tell the end-user.

The FROG-PM operator is engineered and built by Came Cancelli Automatici S.p.A. in compliance with current safety regulations, to
automate residential and aparment building siwng-gates.

Any installation and use other than that specified in this manual is forbidden.

N.B. Over 3.5 m requires an electro-lock.

Model

FROG-PM4

FROG-PM6

Max gate-leaf width (m)

3.5

4.5

5.5

4

5

6

7

Max gate-leaf weight (Kg)

1100

900

700

1000

800

650

550

Model

FROG-PM4

FROG-PM6

Power supply

230V AC 50/60 Hz

230V AC 50/60 Hz

Motor power supply

230 V AC 50/60 Hz

230 V AC 50/60 Hz

Maximum draw.

5.1 A

2.6 A

Power rating

1200 W

600W

Maximum Torque.

800 N

800 N

Opening time (90°)

30 S

45 S

Reduction ratio

1/2016

1/2016

Duty cycle

50%

50%

Protection rating

IP 67

IP 67

Motor heat protection

150°C

150°C

Weight

The operator is made up of a foundation box, a release group, a gearmotor and a transmission arm.

Below-surface 230 V. A.C. gearmotors
001FROG-PM4 - Irreversible gearmotor with encoder for gate leaves of up to 5.5 m.
001FROG-PM6 - Irreversible gearmotor with encoder for gate leaves of up to 7 m.

230 V A.C. control panel
002ZM3EP - Multifunction control panel for swing gates with two leaves with warning display, self-diagnosing safety devices and

built-in radio decoding.

Accessories
001FROG-PC - Foundation boxCassa di fondazione in acciaio con trattamento anticorrosione in cataforesi, completa di leva di tra-

smissione con fermo anta in apertura regolabile.

001A4801 - Limit switch assembly
001A4364 - Lever-key release.
001A4365 - Trilobe-key release.
001A4366 - Custom-key release and EURO-DIN cylinder.
001LOCK81 - Single cylinder locking electro-lock.
001LOCK82 - Double cylinder locking electro-lock.
