II
INTRODUCTION
SYSTEMS WITH NON-AIR GAP FAUCET (MODEL 12301 SHOWN)
SYSTEMS WITH AIR GAP FAUCET, MODELS 12302 AND 12303 (MODEL 12303 SHOWN)
REVERSE OSMOSIS SYSTEM PRODUCT WATER FAUCETS
Item Description Part No. Item Description Part No.
3
4
Chrome-Plated Metal, Non-Air Gap
Chrome-Plated Metal, Air Gap
Connector, Faucet 3/8” x 7/16” (with Faucet)
Page 7, Fig 7
--------
INSTALLATION KIT
Item Description Part No.
1
2
Without Water Quality Monitor
3 Vessel Module, 50 GPD
Without Water Quality Monitor
4 Vessel Module, 15 GPD
4 Vessel Module, 25 GPD
4 Vessel Module, 50 GPD
4 Vessel Module, 75 GPD
Push Button Smartap
®
Water Quality Monitor
4 Vessel Module, 15 GPD
4 Vessel Module, 25 GPD
4 Vessel Module, 50 GPD
4 Vessel Module, 75 GPD
Reverse Osmosis Membrane Filter
9 GPD, Yellow Casing, Red Tape
25 GPD, Yellow Casing, Black Tape
50 GPD, Yellow Casing, White Tape
75 GPD, Yellow Casing, Blue Tape
See
Page 10,
Figure
10A
for
Parts
See
Page 11,
Figure 10B
For Parts
33001071
33001068
33001033
33001056
5
6
7
8
9
10
11
n/s**
n/s**
Complete Kit, Non-Air Gap
Complete Kit, Air Gap
Supply Valve, Saddle-Tapping
Drain Clamp, Saddle Clamp
Connector, Male 1/4" x 1/4" NPT (Non-Air Gap)
Connector, Male 3/8" x 1/4" NPT (Air Gap)
Tubing, 3/8” x 48” Red
Tubing, 3/8” x 48” Blue
Tubing, 3/8” x 48” White
Tubing, 1/4” x 48” White
Screw, Mounting Bracket (2 each)
** not shown
Owner’s Guide
42903014
42903004
34900013
42000002
33503312
33503314
20300018
20300013
20300012
20300014
32701006
36101265
Figure 1A: Component and Interconnection Locators, Models 12301, 12302, and 12303.
NOTE: This Owner’s Guide covers all components that may be included with a system. Information
relating to any component that is not included with your system may be disregarded.
