Hydrotech 12301_12302_12303 Series ADVANCED REVERSE OSMOSIS WATER TREATMENT SYSTEMS User Manual
Page 14
10
Item
Description
Part No.
MODEL 12301
FLOW RESTRICTOR
LABEL
1
1A
2
3
4
5
6
7
8
9
10
11
12
12A
13
14
15
16
17
18
19*
19A*
20
21
22
23
23A
24
25
26
26A
27
28
29
30
31
32*
Cover, 3-vessel Manifold
Cover, 4-vessel Manifold
Bracket, Mounting
Screw, Mounting Bracket
Screw, inlet Valve Cover
Cover, Inlet Valve
"O" Ring, Inlet Valve Cover
Shut Off Assembly
Tubing, 1/4” x 48” White
Elbow, 1/4" Stem w/white collet
Cap, Flow Control w/”O” Ring
Elbow, 1/4" Stem w/red collet
Flow Restrictor, Model 12301 Series
50 GPD
Flow Restrictor, 12302/12303 Series
9 GPD
25 GPD
50 GPD
75 GPD
Elbow, 3/8" Stem w/blue collet
Tubing, 3/8” x 48” Blue
Check Valve, Duckbill
Retainer, Outlet Assembly
Tubing, 3/8” x 48” White
Stop, Tube
Manifold 3 Vessel Qualified No Monitor
Manifold 4 Vessel Qualified No Monitor
"O" Ring, Cartridge
"O" Ring, Membrane Flow Tower
Cartridge, Carbon AES
Cartridge, Sediment/Carbon Filter
Cartridge, String-Wound Pre-Filter
Housing, Filter
"O" Ring, Filter Housing
Filter, Membrane Thin Film Composite
50 GPD, Yellow Casing White Tape
Filter, Membrane Thin Film Composite
9 GPD, Yellow Casing Red Tape
25 GPD, Yellow Casing Black Tape
50 GPD, Yellow Casing White Tape
75 GPD, Yellow Casing Blue Tape
Optional Smartap Push Button Monitor
Cover, 4-vessel Manifold – Push Button
Monitor
Battery, 9-volt alkaline
Monitor, Water Quality - P/B Smartap
®
Push Button, Monitor
Guard, Push Button
Manifold 4 vessel Qualified P/B Monitor
20500067**
20500068**
21100001
32701006
32701038
20500066
34201024
40600010
20300014
33503502
40600050
33503505
40600041
40600034
40600040
40600041
40600042
33503503
20300013
42500014
40600033
20300012
20500094
41300050
41300045
34201010
34201006
41400075
41400076
41400008
20500023
34201026
33001033
33001071
33001068
33001033
33001056
20500068**
31300001
40200002
20500080
20500050
41300052
* Includes Item Numbers 4, 5, 6, 7, 9, 10, 11, 13, 15, 16, 18
**To obtain the correct replacement contact your dealer for the item
number of your system.
Figure 10.A:
Exploded Schematic, 12301 Model Series; Parts List for All Models
