OPERATION
RX60/72/84 03/09
Operation Section 4-3
© 2009 Alamo Group Inc.
OPERA
T
ION
1.
Standard Equipment and Specification
RX60
RX72
RX84
Horsepower Required *(Min)
35 Min. HP
45 Min. HP
65 (Lift) 30(Pull)
Cutting Capacity (Max.)
2-1/2”
2-1/2”
2-1/2”
Cutting Height (Min)
1-1/2” Min.
1-1/2” Min.
1-1/2’ Min
Safety Deflector
Std.
Std.
Std.
Cutting Width
60”
72”
84”
Overall Length
111”
123”
138-1/2”
Weight (Approx.)
998 lbs.
1158 lbs.
1540 lbs.
Hitch
CAT I, II, II Q.H.
CAT I, II, II Q.H.
CAT II, III QH, or Pull
Blade Carrier
-------- All Units use Cross Braced, Round Pan Blade Carrier --------
Blade Tip Speed (FPM) 540 RPM
13,572
16,286
16,328
1000 RPM
n/a
n/a
15,994
Gearbox Rating** 540 RPM
130 HP*
130 HP*
130 HP*
Output Shaft Diameter
2”
2”
2”
Driveline Size
Cat 4
Cat 4
Cat 4
Driveline Protection
Slip Clutch
Slip Clutch
Slip Clutch
Deck Thickness
10 Ga.
10 Ga.
10 Ga.
Side Skirt
1/4” x 11”
1/4” x 11”
1/4” x 11”
Transport Width
67-1/2”
79-1/2”
89-1/2”
Replaceable Skid Shoes
Std.
Std.
Std.
*Ratings based on actual field performance.
** Ratings based on actual field performance
EXTRA EQUIPMENT
OPTIONAL EQUIPMENT
Check Chains (Lift-Type)
Front and Rear Single or Double Chain Guards
Offset Adapter (RX60-RX72)
1 or 2 Tailwheels (RX84 Lift-Type)
Spring Shock Absorber (284 Pull-Type)
540 or 1000 RPM (RX84)
Foam-Filled Used AirplaneTire & Wheel
Laminated, Used Airpland Tire & Wheel
15” Wheel, or Implement Tire and Wheel (RX84 Pull)
The Mower is designed for certain mowing applications and is rated to cut up to a specific
size vegetation (see Mower Standard Equipment and Specifications). DO NOT use this
mower to cut vegetation above the Mower’s rated capacity or to cut any type of non-
vegetative material. Only operate this Mower on a properly sized and equipped Tractor.
Operating this Mower in an application for which it is not designed and/or operating the
Mower with the wrong size Tractor can cause Mower component damage and equipment
failure resulting in possible serious injury or death.
(SGM-14)
