MAINTENANCE
RX60/72/84 03/09 Maintenance Section 5-5
© 2009 Alamo Group Inc.
MAINTENANCE
GEARBOX
The gearbox should be full (3 quarts) and not
require additional lubricant unless the box is
cracked or a seal is leaking. It is recommended that
the oil level dipstick (Figure MntP-R-0056) be
removed to check oil level after every 8 hours of
operation. If required, oil should be added until it
comes to proper level..
Recommended lubricant is multi-purpose gearoil,
Servis-Rhino P/N 00786250.
NOTE: Make sure mower is level when checking oil
in the gearbox.
Gearbox capacity is 3 quarts.
NOTE: Overfilling of Gearbox will cause pressure
to build up and cause Grease Seals to leak.
TAIL WHEEL ASSEMBLY
Tail Wheel Bearings are packed at the factory with heavy-duty bearing grease. Grease Fittings are provided in
the Wheel Hub and Tail Wheel Beam. Grease after 10 hours of use. Figure Mnt-0004.
