Alamo RX72 EN - Manual (Page 137)

OPERATION
RX60/72/84 03/09 Operation Section 4-41
© 2009 Alamo Group Inc.
OPERA
T
ION
To disconnect the mower, first extend the tractor 3-
point hitch top link to remove tension on the top link
hitch pin. When the pin is loose and easy to rotate,
remove the pin from the mower. Next remove both
lower hitch pins.
After disconnecting the 3 lift points, remove the
mower driveline from the tractor PTO shaft. Lay the
driveline down carefully on support flat to avoid
damaging the driveline or its shield. Do not let the
driveline fall into mud or dirt, which can contaminate
the bearing and shorten the life of the driveline.
OPS-R-0031_B
