A S U S A 7 V 4 0 0 - M X S E A S U S A 7 V 4 0 0 - M X S E A S U S A 7 V 4 0 0 - M X S E A S U S A 7 V 4 0 0 - M X S E A S U S A 7 V 4 0 0 - M X S E 2 - 1 3 2 - 1 3 2 - 1 3 2 - 1 3 2 - 1 3
H e a d H e a d H e a d H e a d H e a d
Configures the number of read/write heads. Refer to the drive documentation
to determine the correct value. To make changes to this field, set the IDE
Primary Master field to [Manual] and the Access Mode to [CHS].
Sector Sector Sector Sector Sector
Configures the number of sectors per track. Refer to the drive
documentation to determine the correct value.
PIO Mode PIO Mode PIO Mode PIO Mode PIO Mode
Sets the PIO mode. Configuration options: [Auto] [Mode 0] [Mode 1]
[Mode 2] [Mode 3] [Mode 4]
UDMA Mode UDMA Mode UDMA Mode UDMA Mode UDMA Mode
Sets the UDMA transfer mode. Configuration options: [Disabled] [Auto]
Transfer Mode Transfer Mode Transfer Mode Transfer Mode Transfer Mode
Sets the transfer mode. Configuration options: [Auto] [UDMA0] [UDMA1]
[UDMA2] [UDMA3] [UDMA4] [UDMA5]
First/Second SATA Master First/Second SATA Master First/Second SATA Master First/Second SATA Master First/Second SATA Master
Extended IDE Drive [Auto] Extended IDE Drive [Auto] Extended IDE Drive [Auto] Extended IDE Drive [Auto] Extended IDE Drive [Auto]
Sets the installed SATA hard disk drive as an extended IDE drive.
Configuration options: [Auto] [None]
Access Mode [Auto] Access Mode [Auto] Access Mode [Auto] Access Mode [Auto] Access Mode [Auto]
The default [Auto] enables or disables the LBA mode for the SATA hard
disk drive. Configuration options: [Auto] [Large]
First SATA Master
Extended IDE Drive [Auto]
Access Mode [Auto]
Capacity 82 GB
Cylinder 39420
Head 16
Precomp 0
Landing Zone 39419
Sector 255
F1 : Help
↑↑↑↑↑↓↓↓↓↓
: Select Item -/+ : Change Value F5 : Setup Defaults
ESC : Exit
→← →← →← →← →←
: Select Menu Enter : Select Submenu F10: Save and Exit
Select Menu
Item Specific Help
Press [Enter] to
select.
