A S U S A 7 V 4 0 0 - M X S E A S U S A 7 V 4 0 0 - M X S E A S U S A 7 V 4 0 0 - M X S E A S U S A 7 V 4 0 0 - M X S E A S U S A 7 V 4 0 0 - M X S E 1 - 1 5 1 - 1 5 1 - 1 5 1 - 1 5 1 - 1 5
Standard interrupt assignments Standard interrupt assignments Standard interrupt assignments Standard interrupt assignments Standard interrupt assignments
I R Q I R Q I R Q I R Q I R Q P r i o r i t y P r i o r i t y P r i o r i t y P r i o r i t y P r i o r i t y S t a n d a r d F u n c t i o n S t a n d a r d F u n c t i o n S t a n d a r d F u n c t i o n S t a n d a r d F u n c t i o n S t a n d a r d F u n c t i o n
0 1 System Timer
1 2 Keyboard Controller
2 - Re-direct to IRQ#9
4 12 Communications Port (COM1)*
5 13 IRQ holder for PCI steering*
6 14 Floppy Disk Controller
7 15 Printer Port (LPT1)*
8 3 System CMOS/Real Time Clock
9 4 IRQ holder for PCI steering*
10 5 IRQ holder for PCI steering*
11 6 IRQ holder for PCI steering*
12 7 PS/2 Compatible Mouse Port*
13 8 Numeric Data Processor
14 9 Primary IDE Channel
15 10 Secondary IDE Channel
* T h e s e I R Q s a r e u s u a l l y a v a i l a b l e f o r I S A o r P C I d e v i c e s . * T h e s e I R Q s a r e u s u a l l y a v a i l a b l e f o r I S A o r P C I d e v i c e s . * T h e s e I R Q s a r e u s u a l l y a v a i l a b l e f o r I S A o r P C I d e v i c e s . * T h e s e I R Q s a r e u s u a l l y a v a i l a b l e f o r I S A o r P C I d e v i c e s . * T h e s e I R Q s a r e u s u a l l y a v a i l a b l e f o r I S A o r P C I d e v i c e s .
IRQ assignments for this motherboard IRQ assignments for this motherboard IRQ assignments for this motherboard IRQ assignments for this motherboard IRQ assignments for this motherboard
When using PCI cards on shared slots, ensure that the drivers support
“Share IRQ” or that the cards do not need IRQ assignments; otherwise,
conflicts will arise between the two PCI groups, making the system
unstable and the card inoperable.
A A A A A B B B B B C C C C C D D D D D
PCI slot 1 — — used —
PCI slot 2 — — — used
PCI slot 3 shared — — —
AGP slot — shared — —
