Brooks Instrument SLA5810/20 User Manual
Page 12
1-6
Models SLA5810 and SLA5820
Section 1 Introduction
Installation and Operation Manual
X-PR-SLA5800-PC-eng
Part Number: 541B091AAG
July, 2010
Figure 1-3 Models SLA5810A and SLA5820A Analog I/O Pressure Controllers
Figure 1-4 Models SLA5810D and SLA5820D Digital I/O DeviceNet Pressure Controllers
FITTING
"X" DIMENSION
1/8 Tube Comp.
4.83 [122.7]
1/4 Tube Comp.
5.03 [127.8]
3/8 Tube Comp.
5.15 [130.8]
1/4 Male VCR
4.88 [124.0]
1/4 Male VCO
4.63 [117.6]
3/8-1/2 Male VCR
5.47 [138.9]
3/8-1/2 Male VCO
5.07 [128.8]
1/4 Female NPT
4.94 [125.5]
6mm Tube Comp.
5.03 [127.8]
10mm Tube Comp.
5.17 [131.3]
* OVERALL LENGTH FINGER TIGHT
CONNECTION OPTIONS
1.95
49.5
5.46
138.8
NORM OPEN
VALVE
3.67 [93.2]
NORM CLOSED
VALVE
3.95
100.3
.50
12.7
3.07
77.9
"X"
"ZERO"
BUTTON
.50
12.7
1.48
37.7
4.56
115.9
.99
25.1
NOTES:
1. WIRE SIZE: AWG #14-24
2. PINS 1, 9, & 10 ARE
INTERNALLY CONNECTED ON
THE PRINTED CIRCUIT ASSEMBLY.
3. VALVE OVERRIDE REFERENCED TO
SETPOINT COMMON.
.18
4.4
2.72
69.0
.35
9.0
.71
18.0
INCH/[MM]
8-32 UNC X 17/64 DEEP
MOUNTING HOLES (2 PLCS)
STAT
15 PIN MALE "D"
CONNECTOR DETAIL
D-CONNECTOR CONNECTIONS
PIN #
FUNCTION
1
Setpoint Command Input (-)
2
Signal, 0(1)-5 volt, Output (+)
3
Not Connected
4
5
Power Supply, +15 Vdc or +24 Vdc (+)
6
7
8
9
Power Supply, Common (-)
10
Signal, Common, Output, (-)
11
Reference, +5 Vdc, Output, (+)
12
Valve Override, Input
13
Calibration Select, Input
14
Chassis Ground
15
External Sensor, Input
15
9
8
1
Signal, 0(4)-20 mA, Output (+)
Not Connected
Setpoint, 0(4)-20 mA, Input (+)
Setpoint, 0(1)-5 volt, Input (+)
