BJM Pumps SKX SERIES SHREDDER PUMPS - Manual (Page 28)

28
27-2 Oil Sensor Cable 201713 201713 201713 201713 201713 201713 201713 201713 201713 201713
27-2-1 O-Ring Kit Only Kit Kit Kit Kit Kit Kit Kit Kit Kit Kit
27-3 Seal Minder Cap 201718 201718 201718 201718 201718 201718 201718 201718 201718 201718
31D Oil Sensor w/Wire and Ring Term. 202408 202408 202408 202408 203999 203999 204001 204001 204001 204001
31E Ground Wire w/Ring Term. 203145 203145 203145 203145 203145 203145 203145 203145 203145 203145
32 Power Cord Line Clip / Strain Relief 203166 203166 203161 203161 202504 202499 202499 202499 202500 202500
33 Oil Sensor Cord Line Clip 203163 203163 203163 203163 203163 203163 203163 203163 203163 203163
34 Handle / Chain Handle 202517 202517 202517 202517 202510 202510 - - - -
34 Lifting Ring - - - - - - 202520 202520 202520 202520
35 Rod Bolts 202682 202683 202684 202685 202686 202687 202676 202677 202678 202679
38 Discharge Nippple 2" 202532 - 202532 - - - - - - -
38 Discharge Nipple 3" - 202535 - 202535 202535 202535 - - - -
38E Discharge Elbow 202571 202559 202571 202559 202559 202559 202573 202573 202574 202574
38E-1 O-Ring, Discharge Elbow FKM 203326 203327 203326 203327 203327 203327 - - - -
38E-1 Gasket, Discharge Elbow FKM - - - - - - 203211 203211 202664 202664
38E-1 Gasket, Disch. Elbow Buna-N (Optional) - - - - - - 203210 203210 202663 202663
38F Discharge Flange 2" 202563 - 202563 - - - - - - -
38F Discharge Flange 3" - 202546 - 202546 202546 202546 - - - -
38F Discharge flange 4" - - - - 202553 202553 202576 202576 - -
38F Discharge flange 6" - - - - - - - - 202549 202549
38F-1 O-Ring 2" Discharge Flange FKM 202723 - 202723 - - - - - - -
38F-1 O-Ring, 3" Discharge Flange FKM - 202724 - 202724 202724 202724 - - - -
38F-1 O-Ring, 4" Discharge Flange FKM - - - - 203328 203328 - - - -
38F-1 Gasket, 4" Discharge Flange FKM - - - - - - 202662 202662 - -
38F-1 Gasket, 6" Discharge Flange FKM - - - - - - - - 202664 202664
38F-1 Gasket, 4" Disch. Flange Buna-N (Optional) - - - - - - 202661 202661 - -
38F-1 Gasket, 6" Disch. Flange Buna-N (Optional) - - - - - - - - 202663 202663
50-01-2 Bolt for Strainer/Stand 203228 203228 203228 203228 203228 203228 203236 203236 203279 203279
50-02 Bolt for Suction Cover - - - - - - 203236 203236 203279 203279
50-07 Screw for Oil Chamber/Motor Housing 203296 203296 203296 203296 203296 203296 203271 203271 203280 203280
50-08 Screw for Oil Chamber Cover 203219 203219 203219 203219 203219 203219 203246 203246 203281 203281
50-11 Screw for Oil Fill 203218 203218 203218 203218 203218 203218 203261 203261 203282 203282
50-11-1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit Kit Kit Kit Kit
50-11V Air Release Valve - - - - - - 202707 202707 202707 202707
50-12 Screw for Pressure Check 203218 203218 203218 203218 203218 203218 203218 203218 203218 203218
50-12-1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit Kit Kit Kit Kit
50-13-2 Screw for Seal Retainer - - - - - - 203214 203214 203214 203214
50-14-2 Screw for Bearing Retainer Plate 203219 203219 203219 203219 203219 203219 203220 203220 203220 203220
50-19 Screw for Gov. Switch Plate 202693 202693 - - - - - - - -
50-23 Screw for Overload 202700 202700 202700 202700 202700 202700 202700 202700 202700 203285
50-27 Screw for Power Cord 203295 203295 203295 203295 203246 203246 203246 203246 203246 203246
50-27-2 Screw for Sensor Cord 203295 203295 203295 203295 203295 203295 203295 203295 203295 203295
50-31E Screw for Ground Wire 202692 202692 202692 202692 202692 202692 202692 202692 202692 202692
50-32/50-33 Screw for Line Clip 203214 203214 203214 203214 - - - - - -
50-32-1 Bolt for Power Cord Strain Relief Chain - - - - - 203284 203284 203284 203284
50-34 Screw for Handle 203219 203219 203219 203219 - - - - - -
50-38E Bolt for Discharge Elbow 203294 203271 203294 203271 203271 203271 203276 203276 203278 203278
50-38F Bolt for Discharge Flange 203229 203294 203229 203294 203294 203294 203277 203277 203278 203278
202630 202630 202647 202647 202642 202642 202652 202652 203202 203202
- - - - - - 202651 202651 203201 203201
O-Ring Kit - FKM
O-Ring Kit - Buna-N (Optional)
