BJM Pumps SKX SERIES SHREDDER PUMPS - Manual (Page 27)

27
SKX SERIES PARTS LIST
Pump Model SKX750CSS SKX1500CSS SKX08CSS SKX15CSS SKX22CSS SKX37CSS SKX55CSS SKX75CSS SKX110CSS SKX150CSS
Pos. No. Part Description Item # Item # Item # Item # Item # Item # Item # Item # Item # Item #
01-2 Stand Only 201988 201995 201988 201995 201989 201994 201999 201999 202001 202001
02 Suction Cover - - - - - - 202881 202881 202040 202040
03 Impeller Nut - - 202894 202894 202894 202894 202897 202897 202897 202897
04 Impeller Washer - - 202907 202907 202907 202907 202917 202917 202917 202917
05 Impeller 202951 202125 202958 202962 202965 202968 202137 202139 202946 202948
06 Impeller Key - - 202140 202140 202140 202140 202146 202146 202146 202987
07 Pump Housing 202176 202172 202176 202172 202177 202181 202190 202190 202194 202194
07-1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit - - - -
08 Oil Chamber Cover 202214 202214 202214 202214 202219 202219 202222 202222 202224 202224
08-1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit Kit Kit Kit Kit
09 Lip Seal FKM 202232 202232 202232 202232 202235 202235 202243 202243 202243 202243
09 Lip Seal Buna-N (Optional) 203051 203051 203051 203051 202234 202234 202238 202238 202238 202238
09 Lip Seal EPDM (Optional) 203052 203052 203052 203052 203054 203054 203061 203061 203061 203061
12 Lip Seal for Lower Bearing - - - - - - 203055 203055 - -
13 Mechanical Seal FKM** 200500 200500 200500 200500 200301 200301 200307 200307 200307 200307
13 Mechanical Seal Buna-N (Optional) 200501 200501 200501 200501 200302 200302 200308 200308 200308 200308
13-2 Mechanical Seal Retainer - - - - - - 202273 202273 202273 202273
14 Lower Ball Bearing (*=qty 2 Needed) 200958 200958 200958 200958 200959 200959 200962 200962 200962* 200962*
14-2 Lower Bearing Retainer 202279 202279 202279 202279 202279 202279 203075 203075 203076 203076
14-3 Lock Nut & Lock Washer 200424 200424
17 Rotor w/ Shaft 115/230V, 1PH 203089 203093 - - - - - - - -
17 Rotor w/ Shaft, 3PH - - 202308 202312 202316 202320 202334 202336 202338 202340
18 Stator w/ Casing 115V, 1PH 200513 - - - - - - - - -
18 Stator w/ Casing 230V, 1PH 200571 200516 - - - - - - - -
18 Stator w/ Casing 208V, 3PH - - 200526 200530 200534 200538 200671 - - -
18 Stator w/ Casing 230/460V,3PH - - 200548 200552 200556 200560 200574 200578 200582 -
18 Stator w/ Casing 460V,3PH - - - - - - - - - 200586
18 Stator w/ Casing 575V, 3PH - - 200590 200594 200598 200602 200618 200624 200631 200638
19 Governor Switch w/Switch Plate 202360 202360 - - - - - - - -
20 Upper Ball Bearing 200967 200967 200967 200967 200958 200958 200968 200968 200968 200968
20-1 O-Ring (Kit Only) - - - - - - Kit Kit Kit Kit
21A Oil Chamber/Motor Housing 202197 202197 202197 202197 202198 202198 202200 202200 202201 202201
21A-1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit Kit Kit Kit Kit
21B Motor Cover Upper 202368 202368 - - - - - - - -
23 Overload Protector 115V, 1PH 202383 - - - - - - - - -
23 Overload Protector 230V, 1PH 202395 202383 - - - - - - - -
23 Overload Protector 208V, 3PH - - 202385 202388 202390 202392 202394 - - -
23 Bolt - Suction Cover - - 202385 202388 202390 202392 202394 202396 202397 -
23 Overload Protector 460V, 3PH - - 202387 202386 202389 202391 202393 202394 202398 202397
23 Overload Protector 575V, 3PH - - 202399 202387 202386 202389 202391 202393 202394 202398
24 Capacitor 115V 202417 - - - - - - - - -
24 Capacitor 230V 202418 202420 - - - - - - - -
26 Pump Top Cover (w/ Sensor opening) 202434 202434 202436 202436 202818 202438 203130 203130 202443 202444
26-1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit Kit Kit Kit Kit
27 Power Cable w/ Gland- 115V, 1PH 201696 - - - - - - - - -
27 Power Cable w/ Gland- 230V, 1 PH, No Plug 201695 201695 - - - - - - - -
27 Power Cable w/ Gland- 3PH - - 201702 201702 203443 203445 203447 203447 203449 203449
27-1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit Kit Kit Kit Kit
