BJM Pumps SKX SERIES SHREDDER PUMPS - Manual (Page 26)

26
27 Power Cable w/ Gland- 230V,1PH, No Plug 201694 201694 - - - - - - - -
27 Power Cable w/ Gland- 3PH - - 201701 201701 203442 203444 203446 203446 203448 203448
27-1 O-Ring Kit Only Kit Kit Kit Kit Kit Kit Kit Kit Kit Kit
27-2 Oil Sensor Cable 202763 202763 202763 202763 202763 202763 202763 202763 202763 202763
27-2-1 O-Ring Kit Only Kit Kit Kit Kit Kit Kit Kit Kit Kit Kit
27-3 Seal Minder Cap 203139 203139 203139 203139 203139 203139 203139 203139 203139 203139
31D Oil Sensor w/Wire and Ring Term. 202408 202408 202408 202408 203999 203999 204001 204001 204001 204001
31E Ground Wire w/Ring Term. 203145 203145 203145 203145 203145 203145 203145 203145 203145 203145
32 Power Cord Line Clip / Strain Relief 203161 203161 203161 203161 204161 202497 202497 202497 202500 202500
33 Oil Sensor Cord Line Clip 203163 203163 203163 203163 203163 203163 203163 203163 203163 203163
34 Handle / Chain Handle 202517 202517 202517 202517 202509 202509 - - - -
34 Lifting Ring - - - - - - 203172 203172 203172 203172
35 Rod Bolts 202666 202668 202669 202670 202671 202672 202676 202677 202678 202679
38 Discharge Nippple 2" 202531 - 202531 - - - - - - -
38 Discharge Nipple 3" - 202534 - 202534 202534 202534 - - - -
38E Discharge Elbow 202570 202558 202570 202558 202558 202558 202572 202572 203187 203187
38E-1 Gasket, Discharge Elbow Buna-N 203212 203208 203212 203208 203208 203208 203210 203210 202663 202663
38E-1 Gasket, Disch. Elbow FKM (Optional) 203213 203209 203213 203209 203209 203209 203211 203211 202664 202664
38F Discharge Flange 2" 202562 - 202562 - - - - - - -
38F Discharge Flange 3" - 202545 - 202545 202545 202545 - - - -
38F Discharge Flange 4" - - - - 202552 202552 202575 202575 - -
38F Discharge Flange 6" - - - - - - - - 202548 202548
38F-1 Gasket, Discharge Flange Buna-N 203206 202659 203206 202659 202659 202659 202661 202661 202663 202663
38F-1 Gasket, Disch. Flange FKM (Optional) 203207 202660 203207 202660 202660 202660 202662 202662 202664 202664
50-01-2 Bolt for Strainer/Stand 203228 203228 203228 203228 203228 203228 203236 203236 203279 203279
50-02 Bolt for Suction Cover 203228 203228 203228 203228 203228 203228 203236 203236 203279 203279
50-07 Screw for Oil Chamber/Motor Housing 203228 203228 203228 203228 203228 203228 203271 203271 203280 203280
50-08 Screw for Oil Chamber Cover 203219 203219 203219 203219 203219 203219 203246 203246 203281 203281
50-11 Screw for Oil Fill 203218 203218 203218 203218 203218 203218 203261 203261 203282 203282
50-11-1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit Kit Kit Kit Kit
50-11V Air Release Valve - - - - - - 202707 202707 202707 202707
50-12 Screw for Pressure Check 203218 203218 203218 203218 203218 203218 203218 203218 203218 203218
50-12-1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit Kit Kit Kit Kit
50-13-2 Screw for Seal Retainer - - - - - - 203214 203214 203214 203214
50-14-2 Screw for Brg. Retainer 203219 203219 203219 203219 203219 203219 203220 203220 203220 203220
50-19 Screw for Gov. Switch Plate 202693 202693 - - - - - - - -
50-23 Screw for Overload 202700 202700 202700 202700 202700 202700 202700 202700 202700 203285
50-27 Screw for Power Cord 203216 203216 203216 203216 203246 203246 203246 203246 203246 203246
50-27-2 Screw for Oil Sensor Cord 203216 203216 203216 203216 203216 203216 203216 203216 203216 203216
50-31E Screw for Ground Wire 202692 202692 202692 202692 202692 202692 202692 202692 202692 202692
50-32/50-33 Screw for Line Clip 203214 203214 203214 203214 - - - - - -
50-32-1 Bolt for Power Cord Chain - - - - - - 203284 203284 203284 203284
50-34 Screw for Handle 203219 203219 203219 203219 - - - - - -
50-38E Bolt for Discharge Elbow 203253 203255 203253 203255 203255 203255 203276 203276 203278 203278
50-38F Bolt for Discharge Flange 203289 203289 203289 203289 203289 203253 203277 203277 203278 203278
202629 202629 202636 202636 202638 202638 202651 202651 203201 203201
203197 203197 202646 202646 202641 202641 202652 202652 203202 203202
O-Ring Kit - Buna N
O-Ring Kit - FKM (Optional)
