25
SK SERIES PARTS LIST
Pump Model SK750C SK1500C SK08C SK15C SK22C SK37C SK55C SK75C SK110C SK150C
Pos. No. Part Description Item # Item # Item # Item # Item # Item # Item # Item # Item # Item #
01-2 Stand Only 202847 202858 202847 202858 202850 202855 201998 201998 202000 202000
02 Suction Cover, Cast Iron - - - - - - 202880 202880 202882 202882
02 Suction Cover, Hi-Chrome 202045 202046 202045 202046 202047 202048 - - - -
03 Impeller Nut - - 202894 202894 202894 202894 202897 202897 202897 202897
04 Impeller Washer - - 202907 202907 202907 202907 202917 202917 202917 202917
05 Impeller, Cast Iron 202949 202954 202956 202961 202964 202967 202136 202138 202945 202947
05 Impeller, Hi-Chrome 202122 202953 202126 202960 202963 202966 - - - -
06 Impeller Key - - 202140 202140 202140 202140 202146 202146 202146 202987
07 Pump Housing 202173 203008 202173 203008 203011 203014 203024 203024 203027 203027
08 Oil Chamber Cover 202213 202213 202213 202213 202218 202218 202221 202221 202223 202223
08-1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit Kit Kit Kit Kit
09 Lip Seal Buna-N 203051 203051 203051 203051 202234 202234 202238 202238 202238 202238
09 Lip Seal FKM (Optional) 202232 202232 202232 202232 202235 202235 202243 202243 202243 202243
09 Lip Seal EPDM (Optional) 203052 203052 203052 203052 203054 203054 203061 203061 203061 203061
12 Lip Seal for Lower Bearing - - - - - - 203055 203055 - -
13 Mechanical Seal Buna-N 200501 200501 200501 200501 200302 200302 200308 200308 200308 200308
13 Mechanical Seal FKM** 200500 200500 200500 200500 200301 200301 200307 200307 200307 200307
13-2 Mechanical Seal Retainer - - - - - - 202273 202273 202273 202273
14 Lower Ball Bearing ( * =Qty 2 Needed) 200958 200958 200958 200958 200959 200959 200962 200962 200962* 200962*
14-2 Lower Bearing Retainer 202279 202279 202279 202279 202279 202279 203075 203075 203076 203076
14-3 Lock Nut & Lock Washer 200424 200424
17 Rotor w/ Shaft 115/230V, 1PH 203088 203092 - - - - - - - -
17 Rotor w/ Shaft, 3PH - - 202307 202311 202315 202319 202333 202335 202337 202339
18 Stator w/ Casing 115V, 1PH 200511 - - - - - - - - -
18 Stator w/ Casing 230V, 1PH 200570 200514 - - - - - - - -
18 Stator w/ Casing 208V, 3PH - - 200524 200528 200532 200536 200669 - - -
18 Stator w/ Casing 230/460V, 3PH - - 200546 200550 200554 200558 200572 200576 200580 -
18 Stator w/ Casing 460V, 3PH - - - - - - - - - 200584
18 Stator w/ Casing 575V, 3PH - - 200588 200592 200596 200600 200616 200622 200629 200636
19 Governor Switch w/Switch Plate 202360 202360 - - - - - - - -
20 Upper Ball Bearing 200967 200967 200967 200967 200958 200958 200968 200968 200968 200968
20-1 O-Ring (Kit Only) - - - - - - Kit Kit Kit Kit
21A Oil Chamber/Motor Housing 202196 202196 202196 202196 203030 203030 202199 202199 203032 203032
21A-1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit Kit Kit Kit Kit
21B Motor Cover Upper 202368 202368 - - - - - - - -
23 Overload Protector 115V, 1PH 202383 - - - - - - - - -
23 Overload Protector 230V, 1PH 202395 202383 - - - - - - - -
23 Bolt - Suction Cover - - 202385 202388 202390 202392 202394 - - -
23 Overload Protector 230V, 3PH - - 202385 202388 202390 202392 202394 202396 202397 -
23 Overload Protector 460V, 3PH - - 202387 202386 202389 202391 202393 202394 202398 202397
23 Overload Protector 575V, 3PH - - 202399 202387 202386 202389 202391 202393 202394 202398
24 Capacitor 115V 202417 - - - - - - - - -
24 Capacitor 230V 202418 202420 - - 202818 - - - - -
26 Pump Top Cover (w/ Sensor Opening) 202433 202433 202435 202435 202437 202437 203129 203129 203131 203132
26-1 O-Ring Kit Only Kit Kit Kit Kit Kit Kit Kit Kit Kit Kit
27 Power Cable w/ Gland-115V, 1PH 201693 - - - - - - - - -
