7
Lubrication:
No additional lubrication is necessary. The shaft seal and bearings are fully lubricated
from the factory. Seal oil should be checked once per year. See table below.
OIL FILL QUANTITY/TYPE
OIL IN SEAL CHAMBER
MODEL U.S. FL. OZ. CC. TYPE OF OIL
S750C 7.8 230 ISO 32 NSF Food Grade Mineral Oil
S750C-3 7.8 230 ISO 32 NSF Food Grade Mineral Oil
S1500C 7.8 230 ISO 32 NSF Food Grade Mineral Oil
S08C 7.8 230 ISO 32 NSF Food Grade Mineral Oil
S08C-3 7.8 230 ISO 32 NSF Food Grade Mineral Oil
S15C 7.8 230 ISO 32 NSF Food Grade Mineral Oil
S22C 11.8 350 ISO 32 NSF Food Grade Mineral Oil
S37C 11.8 350 ISO 32 NSF Food Grade Mineral Oil
S55C 35.5 1050 ISO 32 NSF Food Grade Mineral Oil
S75C 35.5 1050 ISO 32 NSF Food Grade Mineral Oil
OIL IN SEAL CHAMBER
MODEL U.S. FL. OZ. CC. TYPE OF OIL
SX750CSS 10.1 300 ISO 32 NSF Food Grade Mineral Oil
SX750CSS-3 10.1 300 ISO 32 NSF Food Grade Mineral Oil
SX1500CSS 10.1 300 ISO 32 NSF Food Grade Mineral Oil
SX08CSS 10.1 300 ISO 32 NSF Food Grade Mineral Oil
SX08CSS-3 10.1 300 ISO 32 NSF Food Grade Mineral Oil
SX15CSS 10.1 300 ISO 32 NSF Food Grade Mineral Oil
SX22CSS 13.5 400 ISO 32 NSF Food Grade Mineral Oil
SX37CSS 13.5 400 ISO 32 NSF Food Grade Mineral Oil
SX55CSS 35.5 1050 ISO 32 NSF Food Grade Mineral Oil
SX75CSS 35.5 1050 ISO 32 NSF Food Grade Mineral Oil
PUMP INSTALLATION
S & SX Series pumps have been evaluated for use with water or water based solutions.
Please contact the manufacturer for additional information.
Risk of electric shock. Pump models; S750C, SX750C, S750C-3,
SX750CSS (115v) are supplied with a grounding conductor and grounding-type
attachment plug. 230V single phase pumps and all three phase pumps do not come
with electric plug connectors. To reduce the risk of electric shock, be certain that it is
connected only to a properly grounded, grounding-type receptacle.
