23

SX SERIES PARTS LIST

Pump Model SX750CSS SX1500CSS SX08CSS SX15CSS SX22CSS SX37CSS SX55CSS SX75CSS

Pos. No.

Part Description

Item #

Item #

Item #

Item #

Item #

Item #

Item #

Item #

01-2

Stand

201985

201987

201985

201987

201991

201993

201997

201997

02

Bottom Plate

-

-

-

-

-

-

202022

202022

03

Impeller Nut

-

-

202894

202894

202894

202894

202897

202897

04

Impeller Washer

-

-

202907

202907

202907

202907

202917

202917

05

Impeller

202095

202097

202101

202104

202106

202108

202111

202113

06

Impeller Key

-

-

202140

202140

202140

202140

202142

202142

07

Pump Housing

202176

202172

202176

202172

202177

202181

202189

202189

07-1

O-Ring (Kit Only)

Kit

Kit

Kit

Kit

Kit

Kit

-

-

08

Oil Chamber Cover

202214

202214

202214

202214

202219

202219

202217

202217

08-1

O-Ring (Kit Only)

Kit

Kit

Kit

Kit

Kit

Kit

Kit

Kit

09

Lip Seal FKM

202232

202232

202232

202232

202235

202235

202241

202241

09

Lip Seal Buna-N (Optional)

203051

203051

203051

203051

202234

202234

202238

202238

09

Lip Seal EPDM (Optional)

203052

203052

203052

203052

203054

203054

203061

203061

09A

Lower Lip Seal FKM

-

-

-

-

-

-

202241

202241

09A

Lower Lip Seal Buna-N (Optional)

-

-

-

-

-

-

202238

202238

09A

Lower Lip Seal EPDM (Optional)

-

-

-

-

-

-

203061

203061

12

Lip Seal for Lower Bearing

-

-

-

-

-

-

202236

202236

13

Mechanical Seal FKM**

200500

200500

200500

200500

200301

200301

200304

200304

13

Mechanical Seal Buna-N (Optional)

200501

200501

200501

200501

200302

200302

200305

200305

14

Lower Ball Bearing

200958

200958

200958

200958

200959

200959

200960

200961

14-1

Lower Ball Bearing

-

-

-

-

-

-

200960

200961

14-2

Lower Bearing Retainer

202279

202279

202279

202279

202279

202279

202279

202279

17

Rotor w/ Shaft 115/230V, 1PH

203089

203093

-

-

-

-

-

-

17

Rotor w/ Shaft, 3PH

-

-

202308

202312

202316

202320

202325

202327

18

Stator w/ Casing 115V, 1PH

200513

-

-

-

-

-

-

-

18

Stator w/ Casing 230V, 1PH

200571

200516

-

-

-

-

-

-

18

Stator w/ Casing 208V, 3PH

-

-

200526

200530

200534

200538

200667

-

18

Stator w/ Casing 230/460V, 3PH

-

-

200548

200552

200556

200560

200564

200568

18

Stator w/ Casing 575V, 3PH

-

-

200590

200594

200598

200600

200607

200611

19

Governor Switch w/Switch Plate

202360

202360

-

-

-

-

-

-

20

Upper Ball Bearing

200967

200967

200967

200967

200958

200958

200959

200959

20-1

O-Ring (Kit Only)

-

-

-

-

-

-

Kit

Kit

21A

Oil Chamber/Motor Housing

202197

202197

202197

202197

202198

202198

203013

203005

21A-1

O-Ring (Kit Only)

Kit

Kit

Kit

Kit

Kit

Kit

Kit

Kit

21B

Motor Cover Upper

202368

202368

-

-

-

-

-

-

23

Overload Protector 115V, 1PH

202383

-

-

-

-

-

-

-

23

Overload Protector 230V, 1PH

202395

202383

-

-

-

-

-

-

23

Bolt - Suction Cover

-

-

202385

202388

202390

202392

202394

-

23

Overload Protector 230V, 3PH

-

-

202385

202388

202390

202392

202394

202396

23

Overload Protector 460V, 3PH

-

-

202387

202386

202389

202391

202393

202394

23

Overload Protector 575V, 3PH

-

-

202399

202387

202386

202389

202391

202393

24

Capacitor 115V

202417

-

-

-

-

-

-

-

24

Capacitor 230V

202418

202420

-

-

202818

-

-

-

26

Pump Top Cover (W/ Sensor opening)

202434

202434

202436

202436

202438

202438

202440

202440
