EXP Computer CRW with USB 2.0 Cable - Manual (Page 22)

- 16 -
SOFTWARE INSTALLATION FOR WINDOWS 2000
1. Boot-up your computer into Windows 2000, making sure the USB port device driver has been
installed and is available. To check this, right-click ‘My Computer’, click ‘Properties’ then
‘Hardware’ and then ‘Device Manager’ to open the ‘Device Manager’ window. Refer to the figures
shown below to see if the USB Controller is installed without error.
2. Ensure the USB interface cable and then the AC adapter connections are made as described in
Hardware Installation. Insert the port connector of the USB interface cable into the USB port of
your computer. The LED on the drive should be light.
USB port of computer Port connector of the USB cable
The above figure indicates this system supports
both USB1.1 and USB2.0 function (the USB2.0
Enhanced Host Controller has been installed).
The above figure indicates this system supports
only USB1.1 function (no USB2.0 Enhanced
Host Controller installed).
