eLine Technology PRO3 Effio E - Manual (Page 13)

23 24
CAMERA ADJUSTMENT CAMERA ADJUSTMENT
LANGUAGE: English,Japanese,German, French
Russian, Portuguese, Spanish, Chinese.
LENS
SETUP MENU
LANGUAGE ENGLISH
LENS AUTO
SHUTTER/AGC AUTO
WHITE BAL ATW
DAY/NIGHT AUTO
PICT ADJUST 
2DNR 
NEXT
EXIT SAVE ALL
Changes the settings of the internal lens..
LENS: MANUAL,AUTO
AUTO IRIS
TYPE DC
MODE AUTO
SPEED 80
RETURN
TYPE:
DC
MODE: AUTO,CLOSE,OPEN
-AUTO: The mechanical iris is controlled automatically
-CLOSE: The mechanical iris is set to the closed position
-OPEN: The mechanical iris is set to the open position
Default setting is Auto
SPEED: 000-255
Sets the convergence speed of the mechanical iris.
Default setting is 80
SHUTTER/AGC
SETUP MENU
LANGUAGE ENGLISH
LENS AUTO
SHUTTER/AGC AUTO
WHITE BAL ATW
DAY/NIGHT AUTO
PICT ADJUST 
2DNR 
NEXT
EXIT SAVE ALL
Shutter has two options either AUTO or MANUAL
AUTO SETUP
HIGH LUMINANCE
MODE SHUT-AUTO IRIS
BRIGHTNESS 40
LOW LUMINANCE
MODE AGC
BRIGHTNESS x0.50
RETURN
MANUAL SETUP
MODE SHUT+AGC
SHUTTER 1/60
AGC 6.00
RETURN
• AUTO SETUP HIGH LUMINANCE
MODE: SHUT
BRIGHTNESS: 000-255
High and medium brightness.
• AUTO SETUP LOW LUMINANCE
MODE: AGC / OFF
Specifies the AE control for medium
and high brightness.
BRIGHTNESS: x0.25 / x0.50 / x0.75 / x1.00
Specifies low brightness reference.
