VIDEO INTERCOM AND ACCESS CONTROL SYSTEM
Specifier Notes: Edit the following sentence for either standard or enhanced hands-free color video
intercom system.
A.
[Standard] [Enhanced] Hands-
Free Color Video Intercom System: Aiphone “JF Series”.
Specifier Notes: Include the following for both standard and enhanced hands-free color video intercom
systems.
1.
Power Source:
a.
18 V DC.
b.
Model PS-1820UL.
2.
Calling:
a.
Chime, image, and audio.
b.
Approximately 45 seconds.
3.
Communication:
a.
Automatic (hands-free): To activate, momentarily press TALK button.
b.
Manual (press-to-talk/release-to-listen): To activate, press TALK button for 1 second
or until talk LED turns on.
4.
Camera: CCD.
5.
Video Monitor:
a.
3.5-inch direct-view TFT color LCD.
b.
Scanning Lines: 525.
c.
Minimum Illumination: 5 Lux at 1 foot.
6.
Night Viewing: Up to 1 foot from camera, with white LED projected, background beyond 1
foot cannot be seen.
7.
Door Release:
a.
Contact Rating: N/O 24 V AC/DC, 500 mA.
b.
Door Release Relay: Model RY-18L for Form C high-current contact.
8.
Wiring:
a.
Door to Master Station: 2 conductor.
b.
Standard Master Monitor Station to Sub Monitor Station: 6 conductor.
c.
Enhanced Master Monitor Station to Sub Monitor Station: 4 conductor.
d.
Mid capacitance, solid, non-shielded.
9.
Distance:
a.
Door to Farthest Standard Monitor Station:
1)
22 AWG: 165 feet.
2)
18 AWG: 330 feet.
b.
Door to Enhanced Master Station:
1)
22 AWG: 165 feet.
2)
18 AWG: 330 feet.
c.
Enhanced Master Station to Farthest Sub Monitor Station:
1)
22 AWG: 165 feet.
2)
18 AWG: 330 feet.
