1. Overview
Introduction
This document contains information for installing, servicing, and
configuring the ADT-APS-6R Auxiliary Power Supply. The table below
contains a list of document sources for supplemental information:
Table 1 Supplemental Documentation
Description
The ADT-APS-6R Auxiliary Power Supply is a 150W cabinet-mounted
power supply, designed to power devices that require filtered, regulated,
non-resettable power, such as XP Transponder modules, Notification
Appliance Circuit Modules and Control Modules. The ADT-APS-6R
provides three 24 VDC (filtered) output circuits.
Figure 1 ADT-APS-6R Auxilliary Power Supply
Control Panels Refer to... Part Number
Unimode 4-16 Unimode 4-16 Installation
Manual A15019
Unimode II Series Unimode II Installation
Manual A15583
Unimode 400 Series Unimode 400 Installation
Manual 50710
Unimode 2020 Unimode 2020 Installation
Manual 51167
ADT Transponder
Series ADT Transponder Manual 50928
All ADT Device Compatibility
Document 51352
