Appendix C - Unimode II & Unimode 2020 Connecting the ADT-APS-6R to an MPS-24B
24
ADT-APS-6R Instruction PN 50935:B 7/21/00
Connecting the ADT-APS-6R to an MPS-24B
Make the following connections as shown in the figure below.
• Connect primary power from TB1 to MPS-24B terminal block
TB1, Pin 3( NEUT ) and Pin 4( HOT )
• Connect secondary power from TB3 to MPS-24B terminal block
TB3, Pin 1(+) and Pin 2(–)
• Connect trouble input from J3 to MPS-24B terminal block P4
Figure 15 Wiring to MPS-24B
J2
J9
J3
J1
TB2
JP3 JP2
JP3
P3
P4
TB3
P1
TB2
TB1
CB1 P2
R55 1 2 3 4 6 7 8
7
5
3
2
1
EARTH AC NEUT CO MMON CO MMON BATT - +2 4 VRESET AC HOT
MPS-24BPCC
REV ___
+2 4 VPOW ER BATT +
TRO UBLES
AC BATT +EF -EF
2 3 4 1 2 3 4 1 2
APS
-6
R t
o
M
P
S-
2
4
B
.c
d
r
