Datamax-O'Neil Performance series Wireless User Manual
Page 12
Wireless Installation Instructions | 1
9
Wireless Installation Guide
11. Insert the cable assembly through the frame and secure it with the included washer
and nut.
Figure: 1 - 10 Cable Assembly
12. Connect the cable assembly to the wireless module sub-assembly and ensure the
connection is secure.
Nut
Washer
Cable Assembly
