Wireless Installation Instructions | 1

7

Wireless Installation Guide

9. Insert the foam strip directly behind the wireless module sub-assembly on the main

PCB board in the outlined area.

Note:

The foam strip is intended to keep the module from accidentally becoming

ejected.

Figure: 1 - 8 Foam Strip
