40

Chapter 1

Keyboard

Item

Specification

Keyboard controller

NS PC97541V

Total number of keypads

84-/85-key

Windows logo key

Yes

Internal & external keyboard work
simultaneously

Plug USB keyboard to the USB port directly: Yes

Battery

Item

Specification

Vendor & model name

Panasonic 3S2P

Battery Type

Li-ion

Pack capacity

6Cell 2.9 MAH

Number of battery cell

6

Package configuration

3 cells in series, 2 series in
parallel

Normal voltage

11.1V

Charge voltage

19.0 v

LCD 12.1” inch

Item

Specification

Vendor & model name

AUO B121EW09 V0 (Glare)

Screen Diagonal (mm)

12.1 inches

Active Area (mm)

261.12 x 163.2

Display resolution (pixels)

1280 x 800 WXGA

Pixel Pitch

0.204 x 0.204

Pixel Arrangement

R.G.B. Vertical Stripe

Display Mode

Normally White

Typical White Luminance (NIT)
also called Brightness

220

Luminance Uniformity

1.25 max

Contrast Ratio

400 typical

Response Time (Optical Rise
Time/Fall Time)msec

16 typ/25 max

Nominal Input Voltage VDD

+3.3V

Typical Power Consumption (watt)

4.5W max

Weight (without inverter)

270 max.

Physical Size(mm)

275.82 x 178 x 5.5 max.

Electrical Interface

1 channel LVDS

Support Color

262,144

Viewing Angle (degree)
Horizontal: Right/Left
Vertial: Upper/Lower

45/45
15/35
