106 Chapter 3
10. Remove the four screws (J) securing the left and right LCD brackets to remove the brackets.
Removing the Antennas
1. See “Removing the Battery Pack” on page 64.
2. See “Removing the Lower Cover” on page 65.
3. See “Removing the WLAN Board Modules” on page 67.
4. See “Removing the Keyboard” on page 71.
5. See “Removing the Middle Cover” on page 72.
6. See “Removing the LCD Module” on page 74.
7. See “Removing the LCD Bezel” on page 100.
8. See “Removing the LCD module with the Brackets” on page 102.
9. Release the antenna cables from the aluminium tapes.
Step Size (Quantity) Color Torque
1~4 M2 x L3 (4) Silver 1.6 kgf-cm
