Communication Concepts MicroDot User Manual
Communication Concepts Hardware
MicroDot Coaxial Cable
Cable Number
260-4118-0000
Impedance (ohms)
25
Capacitance (pf/ft)
58.2
Attenuation (db/FT @ 400MHz)
.25
Inner Conductor Material
24 SPC
Inner Conductor O.D. (Nom.)
.020
Dielectric Material
TFE
Dielectric O.D. (Nom.)
.036
Shield Material
38 SPC
Shield O.D. (Max.)
.058
Jacket Material
FEP
Jacket O.D. (Max.)
.075
Jacket Color
White
SPC Silver Plated Copper
TFE Teflon
FPE Foamed Polyethylene
