ClimaCool UCA Manual - Manual (Page 32)

www.climacoolcorp.com
32
Refrigeration Circuit Diagram
SIZE
ClimaCool Corp.
RefrigDiag-UCA DWG NO
RefriDiag-UCA
REV
SHEET 1 OF 1
REFRIGERATION CIRCUIT DIAGRAM
(CIRCUIT #1 OF 2 SHOWN)
DESCRIPTION
PACKAGE AIR-COOLED MODULAR CHILLER
CLIMACOOL Model # UCA020,030
DATE
03/14/2011 DRAWN BY
Gus Olivera
SCALE
NONE
A
FILENAME
RefriDiag-UCA
REVISED
-
-
APPROVED
DATE
03/14/2011
REVISED
-
TITLE
TXV
BULB
EQUALIZER
LINE
AIR COOLED
CONDENSER SECTION
9
10
6
FLUSH
SHUT-OFF
VALVE
CHILLER
WATER INLET
VALVE
CHILLER
WATER OUTLET
VALVE
FACTORY CHILLER
WATER PIPING
FILL
SHUT-OFF
VALVE
CHILLER INLET
WATER MAIN (6")
PETE'S
PORTS
REFRIGERANT
CIRCU
IT
#
2
REFRIGERANT
CIRCU
IT
#
1
CHILLER OUTLET
WATER MAIN (6")
COMPONENT LEGEND
1. COMPRESSOR
2. HIGH PRESSURE SWITCH
3. HOT GAS BYPASS VALVE (IF USED)
4. HOT GAS BYPASS SOLENOID VALVE (IF USED)
5. AIR COOLED CONDENSER SECTION
6. FILTER DRIER
7. SIGHT GLASS MOISTURE INDICATOR
8. LIQUID LINE SOLENOID VALVE
9. THERMAL EXPANSION VALVE
10. CHILLER EVAPORATOR HX
S1. DISCHARGE TEMPERATURE SENSOR
S2. LEAVING CHILLER WATER TEMP. SENSOR
S3. SUCTION TEMPERATURE SENSOR
PT1. DISCHARGE PRESSURE TRANSDUCER
PT2. SUCTION PRESSURE TRANSDUCER
3
(WHEN USED)
EQUALIZER
LINE
1
2
PT2
PT1
S1
S3
5
CONDENSER
AIR EXHAUST
CONDENSER
AIR INTAKE
(WHEN USED)
(WHEN USED)
7
8
S
S2
SYMBOL LEGEND
S # = TEMPERATURE SENSOR
# = LEGEND ITEM #
= SOLDER JOINT
PT#
= PRESSURE TRANSDUCER
= "TEE" SOLDER JOINT
= REFRIGERANT FLOW PATH
= PRESSURE ACCESS FITTING
= SILVER SOLDER JOINT
= THERMAL EXPANSION VALVE TXV
CONDENSER FAN(S)
TXV
4
S
(WHEN USED)
