TS318SU/TS318TU/TS325TU Installation Instructions
4
DIMENSIONS (continued)
24.46
621.2
16.71
424.5
600
23.62
MAX HORIZONTAL MOUNTING PATTERN
400
15.75
ALIGN CENTER DIAMOND
ON CENTER OF SCREEN
.33
8.3
16.38
415.9 12.88
327
24.46
621.2
20.00
508
15.00
381
1" (25.4)
HEIGHT ADJUSTMENT
100 X 100
100 X 200
200 X 200
MOUNTING PATTERNS
ON FACEPLATE
INTERFACE NOT REQUIRED
MOUNT
CENTERLINE
1.8
DEPTH
[48.2]
1.9
WITH INTERFACE
45.7
17.24
437.9
6.81
173
TS318TU
70°
12.3
DISTANCE TO
C/L OF MOUNT
313.5
MAXIMUM ANGLE
45°
16.37
DISTANCE TO
C/L OF MOUNT
415.9
MAXIMUM CLEARANCE
AT 45°
