Installation Instructions TS318SU/TS318TU/TS325TU
3
DIMENSIONS
90°
C/L OF SCREEN
45°
C/L OF SCREEN C/L OF SCREEN
22.56
573.1
1" (25.4 mm)
HEIGHT ADJUSTMENT
100 X 100
100 X 200
200 X 200
MOUNTING PATTERNS
ON FACEPLATE
INTERFACE NOT REQUIRED
1.8
DEPTH
[48.2]
1.9
WITH INTERFACE
45.7
12.3
313.3
.34
8.64
5.75
146.1
13.5
342.8
2.36
60
24.46
621.2
16.71
424.5
23.62
MAX. HORIZONTAL
PATTERN
600
15.75
MAX. VERTICAL
MAXIMUM WEIGHT CAPACITY
75 LBS. (34 KGS.)
TS318SU
DIMENSIONS: [MILLIMETERS]
INCHES
