CHIEF VCM Series - Manual (Page 3)

Installation Instructions VCM
3
LEGEND
TOOLS REQUIRED FOR INSTALLATION
PARTS
Tighten Fastener
Apretar elemento de fijación
Befestigungsteil festziehen
Apertar fixador
Serrare il fissaggio
Bevestiging vastdraaien
Serrez les fixations
Loosen Fastener
Aflojar elemento de fijación
Befestigungsteil lösen
Desapertar fixador
Allentare il fissaggio
Bevestiging losdraaien
Desserrez les fixations
Hex-Head Wrench
Llave de cabeza hexagonal
Sechskantschlüssel
Chave de cabeça sextavada
Chiave esagonale
Zeskantsleutel
Clй а tête hexagonale
Adjust
Ajustar
Einstellen
Ajustar
Regolare
Afstellen
Ajuster
Open-Ended Wrench
Llave de boca
Gabelschlüssel
Chave de bocas
Chiave a punte aperte
Steeksleutel
Clй а fourche
1/2"
5/32"
(included)
9/16"
B (1)
5/32"
C (1)
5/16-18 x 3/8"
A (1)
[VCM]
D (1)
[HB interface bracket]
(EXAMPLE ONLY - Bracket
varies dependent on projector model)
