Page 41
41
ST15 (Archive Book) 01/04
© 2004 Alamo Group Inc.
Item
Part No.
Part No.
Qty
Description
540 RPM
1000 RPM
02978513
------------
-
Gearbox Asy, 540 RPM
-------------
02978971
-
Gearbox Asy, 1000 RPM
1
02978747
02978747
1
Casing
2
02978748
02978748
2
Bearing
3
02978733
02978733
1
Seal
4
02978749
02978749
1
Shaft, Input
5
02978750
02978750
2
Snap Ring
6
02978751
02978751
2
Shim
7
02978752
02978752
1
Cotter Pin
8
02978753
02978753
1
Nut
9
02978754
-------------
1
Gear, 540 RPM
-------------
02978972
1
Gear, 1000 RPM
10
02978758
02978758
1
Shaft
11
02978755
02978755
1
Sealing lid
12
02978756
02978756
1
Seal
13
02978757
02978757
1
Bearing
14
02978759
02978759
1
Bearing
15
02978760
02978760
1
Shim
16
02978761
02978761
1
Shim
17
02978762
02978462
1
Cap
18
02978763
02978763
4
Bolt
19
02978764
02978764
1
Plug
20
02978765
02978765
1
Cover
21
02978766
------------
1
Gear, 540 RPM
-------------
02978973
1
Gear, 1000 RPM
22
02978571
02978571
1
Nut, Slotted
23
02978569
02978569
1
Flatwasher
24
02978769
02978769
1
Washer, Disc Spring (Coned)
25
02978770
02978770
1
Splined Hub (Ref Only - weld on part)
26
02978572
02978572
1
Cotter pin
GEARBOX ASY.
CENTER DECK
ST15 / ST10
Jan. 2002
to
Current
ST15-C31200557203
to
ST15-Current
NOTE: Gearbox Gear ratio 1000 RPM is 1.2 in : 1 out and a 540 RPM is 1 in : 1.5 out.
