CASTLE, INC
TSM-21 OWNERS MANUAL V2.0
Page 22 of 41
• To raise the pilot hole, slide the plate upward one or two hole positions (each hole position
equals
1
/
16
” of drill position). To lower the pilot hole, slide the plate downward.
• Reattach the nut and bolt in the new hole position, and secure in place.
• Tighten the nut on the plate that is nearest to the carriage axle.
• Repeat for the other side.
• On the outside of the machine, secure the Carriage Centering Screw with a
1
/
8
” allen wrench
and tighten the nuts securing the pivot point of the Motor Carriage to the machine case.
