Schreiber Chillers Modular Chillers User Manual
Page 52
52
Part List
A3000ACMOD-02
Description
Qty
K03.57:KIT: ELECTRICAL SUB-PANEL FOR 30TON
1
E115:GROUND SCREW - A 35 ALUM. CONNECTOR
1
E100:DISCONNECT - 100 AMP
1
E101-S:DISCONNECT SHAFT ONLY
1
E101-H-CE2:DISCONNECT - HANDLE ONLY "CE" RED/Y
1
E107-SD:SINGLE DOUBLE CONNECTOR
10
E107-DEC:DOUBLE END CAP
3
E109-F6:6 AMP FUSE - 600V
1
E126:PILOT LIGHT ASSEMBLY-ALL UNITS-GREE
5
E126-1:REPLACEMENT BULB 24V FOR E126
5
E109:FUSE BLOCK
1
E102-3HP:3HP CONTACTOR - IEC
3
E182:50 AMP IEC CONTACTOR
2
E107-3K:OVERLOAD RELAY 3.0 - 4.7 AMP
3
E150:1.5 HP 3 PH 60 HZ 1725 RPM MOTOR
3
E149:FAN BLADE 24" 16 PITCH
3
E153-24:FAN GUARD FOR 24 BLADE
3
K04.64:KIT:CABIENT FOR 30 TON MOD
1
CA3000-GM:30 TON GREY MODULATING CABINET
1
E136-30:WTR.PRESSURE GA. 2.5"0-160 PSI LIQ.
1
P162:FLOW SW.1" BRASS- 6/166 GPM -150 PS
1
P901:BF003 3" CTS FLANGE
4
P140-2:2" HOSE ADAPTER
2
C3000:30-TON CARTON WITH 3/4" BASE
1
A01:SNAP-IN FLUSH MOUNT RECESSED DOOR H
8
P174:2" 20 MESH Y - STRAINER
1
K06.106:KIT: REFRIGERATION FOR 30 TON CATAL
1
R115-S:15 HP- 460/3 SCROLL COMPRESSOR
2
R184:HIGH PRESS SW. OP/410 - CL/MR
2
R140-15:15 TON TXV
2
R185:LOW PRESS. SW - OP/15 - CL/30 (250+
2
R192:VIBRATOR ELIMINATOR - 1 3/8
2
R128:15 TON AIR COOLED CONDENSER(FOR 30
2
R144-C:24V COIL FOR R144
2
R178BP:30 TON BRAZED PLATE DUAL CIRCUIT-DV
1
R137-3B:2-1/4" X 1-5/8SW ROTALOCK VAVLE
2
R137-2A:7/8"SW - 1-1/4"-12 ROTALOCK VALVE
2
R134:RECEIVER - 7.5 - 25 TON
2
R149:5/8 LIQ LINE SOL. VALVE - 12.5 & 25
2
R146-30A:30 TON TANDEM SIGHT GLASS
2
R188:30 TON LIQUID SUCTION BRZD PLATE HE
2
R156:7/8 DRIER (30 TON)
2
E190D-480:480V - 120 WATT HEATER - ZR250
2
K08.23A:
1
P153:FLOAT SWITCH 1/8 NPT - HALF THRU 5
1
