digital_out_4
+--------------------+
| DIGITAL OUTPUT #4 |
|CONTROL STATE: AUTO|
|OUTPUT STATE: OPEN |
|Fan 2 |
+--------------------+
digital_out_5
+--------------------+
| DIGITAL OUTPUT #5 |
|CONTROL STATE: AUTO|
|OUTPUT STATE: OPEN |
|Fan 3 |
+--------------------+
manual_menu3
+--------------------+
| Manual Control |
| Digital Outputs |
|
|
| Digital Inputs |
+--------------------+
analog_in_1
+--------------------+
| ANALOG INPUT #1 |
|CONTROL STATE: AUTO|
|INPUT STATE: 0000 |
|Head Pressure 1 |
+--------------------+
analog_in_2
+--------------------+
| ANALOG INPUT #2 |
|CONTROL STATE: AUTO|
|INPUT STATE: 0000 |
|Head Pressure 2 |
+--------------------+
analog_in_3
+--------------------+
| ANALOG INPUT #3 |
|CONTROL STATE: AUTO|
|INPUT STATE: 0000 |
|Inlet Temperature |
+--------------------+
analog_in_4
+--------------------+
| ANALOG INPUT #4 |
|CONTROL STATE: AUTO|
|INPUT STATE: 0000 |
|Outlet Temperature |
+--------------------+
