MoTeC
Appendices
23
Pinout
VCS Connectors
Connector A and B (AV1, AV2)
5 pin Autosport connector
Mating connector #65071 (yellow)
Connector C (Power/Comms)
5 pin Autosport connector
Mating connector #65033 (red)
Pin Name
Function
Pin Name
Function
1
Mic In
Microphone In
1
Bat
–
Battery Negative
2 Mic
0V Microphone
0 Volt
2
N/C
3
Cam 12V
Camera 12 Volt
3
Bat+
Battery Positive
4
Cam In
Camera In
4
CAN LO CAN Low
5
Cam 0V
Camera 0 Volt
5
CAN HI CAN High
Connector D
Mini-USB connector
Camera Connector
4 pin Binder Connector
Mating connector #68105
Pin Name
Function
1
Cam Out
Camera Out
2
Cam 0V
Camera 0 Volt
3
Cam 12V
Camera 12 Volt
4
N/C
Microphone Connector
3 pin Binder Connector
Mating connector #68106
Pin Name
Function
1 Mic
0V
Microphone 0 Volt
2
Mic Out
Microphone Out
3
N/C
