16 Configuration
Configure a MoTeC 'hundred series' ECU
The method described here is based on Version 3 ECU Manager software.
Configuration in Version 2 ECU Manager software will be very similar.
1. Open MoTeC ECU Manager and open a file.
2. On the Adjust menu, click General Setup.
3. Click Communications and then click Setup Custom Data Sets.
4. Click the Custom Set 2 tab.
5. Click Add to add the following channels (in this order):
a. Ground Speed
b. Engine RPM
c. Gear
d. Throttle Position
e. Brake Pressure or G Force Longitude
Tip: Use G Force Longitude only if Brake Pressure is not
available in the ECU.
If any of these channels is not available in the ECU, you can disable
them in the VCS configuration template. See Receiving CAN
Messages.
6. Click OK.
7. On CAN Setup, select CAN 0 Data and enter 10 (Custom Data Set 2
Compound Tx).
Note: If CAN 0 is already in use, the VCS should be set up on CAN 1.
8. Select CAN 0 Address and enter 31.
9. Select CAN 0 Transfer Rate and enter 100.
