MoTeC ECU Manager Software 65
View Screen
The View Screen may be shown by pressing the V key or by selecting the
desired view page from the View menu. The View Screen displays all the
operating details of the ECU including:
• Sensor
data
• Diagnostics
errors
• Fuel injection detail including all trims and compensations
• Ignition detail including all trims and compensations
• Boost
control detail
• Status
information
• Output
Status
• Internal voltages etc.
The View Screen has a number of pages that may be accessed by pressing
Tab while holding down the Ctrl key or by pressing the first letter of the
screen name.
It also allows resetting of Diagnostic Errors, Maximum RPM and Fuel Used.
The Diagnostic Errors Screen may be accessed directly by pressing the F3
key.
Note that the View Screen may be viewed with or without the ECU open (but
only if the ECU is connected).
