Section 19: Specifications
Operating Temperature Range -40°C to +55°C
Power Supply
Supply voltage: 48Vdc +/-10%
Reverse polarity protected
Power requirement; 90W nominal at 48V with white strobe in day mode at
40FPM and 550ft of 20AWG cable
Red beacon power requirement nominally 25W when steady burning
Maximum flash rate 40 FPM
Dimensions - 12 x 12.75 Inches
Weight - 10 Pounds
Light Engine
Weight 26 Pounds
Height
(See Flash Head Dimensions on previous page)
7.28 Inches
Diameter
(See Flash Head Dimensions on previous page)
16.05 Inches
Bolt Hold Down Pattern – Standard Pattern provided
(See Base Bottom View)
