VORTEX SILVER SERIES V8
P.26
Latency Zero-latency mode in analog input mode (with DSP off). Pure analog signal path.
Approx. 0,4 ms with DSP off and AES or Uman input
Min. 1,15 ms with DSP on and AES or Uman input
Min. 1,56 ms with DSP on and analog input
Digital Inputs AES – EBU, 16, 18, 20, or 24-bit, 32 – 96 kHz with selectable sample rate converter
Uman digital audio network
AC mains
*: Approximative mains voltage ranges where the amplifier can be used. Amplifier output power
performance will decrease with lower mains voltages than the rated 230 V / 120 V and slightly
increase with higher mains voltages.
Dual-voltage SMPS with automatic voltage range selection 230 V / 120 V, 50 – 60 Hz
Operating voltages*: 230 V range: 180 – 267 V, 120 V range: 70 – 134 V
Neutrik 32 A powerCON ® connector
Selectable FuseProtect limiter to control long-term average mains input current from 8 to
24 A
Operating Temperature +5 °C to +55 °C
Dimensions (W × H × D) 483 Ч 88,1 Ч 452,5 mm / 19 Ч 3,5 Ч 17,2 inches (19”, 2U)
Net Weight 13 kg / 28,7 lbs
Shipping Dimensions (W × H × D) 615 Ч 135 Ч 540 mm (0,045 m3) / 21,3 Ч 5,3 Ч 24,2 inches
Shipping Weight 15,6 kg / 34,4 lbs
We reserve the right to make technical alterations without prior notice
