VORTEX SILVER SERIES V8
P.25
Frequency Response
@ 4 Ω load with 120 W ouptut power
20 Hz – 20 kHz: ± 0,07 dB
THD+N over frequency
@ 4 Ω load with 120 W output power
20 Hz – 17 kHz: <0,1%
Damping Factor
8 Ω load, 1 kHz and below
>400
Input Impedance 22 kΩ balanced
Input Gain Selectable: 26 dB, 32 dB or 1,4 V input sensitivity
Maximum Analogue Differential Input Level +22 dBu / 9,75 Vrms / 13,8 Vp
Level Attenuation 0 dB to −127,5 dB in increasing step width, from 0,5 dB (high end, 0 dB) to 20 (low end,
−127.5 dB)
Minimum Loudspeaker Load Impedance
lower values are safe, but out of specification
no performance guarantees can be given when driving lower impedances than specified
Zmin = 2 Ω for Dual-Channel operation
Zmin = 1 Ω for Parallel Mono operation
Zmin = 4 Ω for Mono Bridge operation
Protection Circuits Inrush-current limitation, protection circuits against power on / off transients, temperature
monitoring of transformers and heatsinks, output DC protection, temperature dependent
SOA protection, intelligent mains fuse protection, SMPS overload protection, overcurrent
limitation, thermal limitation
Limiters Selectable Clip Limiter, selectable FuseProtect Limiter
Cooling Two temperature dependent speed-controlled axial fans
LED Indicators LEDs for Input Selection, Output Mode, Clip, Signal, Device Identification, DSP, and Uman
Input Connectors Two 3-pin XLR female analogue input connectors, pin 2 = hot (inphase)
Two 3-pin XLR male passive loop through connectors
One 3-pin XLR female AES (digital) input connector
Two Uman network connectors (in and out) etherCON
® RJ45
One Ethernet Link connector RJ45
Power Output Connectors One 4-pole SPEAKON ® connector for each output channel (bi-amping possilbe)
Modes of Operation Dual channel (Stereo), mono bridge and parallel mono
Input Sources Analogue, AES, Uman network
A/D – D/A Converters 24 bit / 96 kHz
We reserve the right to make technical alterations without prior notice
