Rev. I-100511 Page 2 P/N VDC28252-AA-Series-MNL
BatteryMINDer ® Model 28252-AA-Series
Aviation charge mode output control: Factory Presets (defaults)
NORMAL
TOLERANCE
UNIT
Max Equalizing Time:
4
±10%
Hours
Float charging output voltage control:
Battery voltage is maintained at 25.8 ~ 26.1
1
±1%
Vdc
Max. Float charging current control
5
±10%
Adc
Restarts Bulk charging when battery voltage is low:
Battery voltage is below 25.2
±2%
Vdc
Battery temperature compensation activity conditions: Battery temperature compensation: value for battery voltage (based on value at 25°C)
Battery series -50mV/°C
±25%
mV/°C
Max. unloaded output voltage when disconnected from battery:
0.5
max.
Vdc
Max. output short-circuit current when disconnected from battery:
3
max.
mAdc
Max. flow back current (to unit) when connected to battery, AC power disconnected
3
max.
mAdc
Remarks:
1
These voltages are for ST
ANDARD A
VIA
TION setting.
The GILL 7000 SERIES, ODYSSEY and HA
WKER setting absorption voltage is
29.4V and float is 27.2V
.
The CONCORDE setting absorption voltage is 28.2V and float is 27.0V
.
If Temperature - Voltage Sensor connection is faulty, detached or loose, unit will automatically run in Normal charge mode = NO TEMPERATURE COMPENSATION Repair or replace before using unit at temperature above 80°F or below 60°F
