Page 3
Accessories
Part
Innerduct
Number
Size
OD
EC1.315
1"
1.19" – 1.242"
EC1.488
1-1/4"
1.546"
EC1.488
1-1/4"
1.488"
EC1.660
1-1/4"
1.660"
EC1.900
1-1/2"
1.890"
EC2.375
2"
2.348"
P75
3/4"
.91 – 1.08"
P100
1"
1.242"
P125
1-1/4"
1.44" – 1.68"
P150CPLR
1-1/2"
1.8" – 2.02"
P200
2"
2.31" – 2.48"
P300
3"
3.495" – 3.505"
P400
4"
4.41" – 4.65"
BS1.315
1" SDR
1.315"
BS1.194
1" True 11
1.194"
BS1.488
11/4" True 11
1.488"
BS1.660
11/4" SDR
1.660"
BS1.900
11/2" SDR
1.900"
BS2.375
2" SDR
2.375"
Part
I.D.
Number
Size
Range
PIC100
1"
1.05"
PIC125
1-1/4"
1.25"
HDPE Innerduct & Accessories
HDPE Innerduct
How to Build a Part Number:
Product
Size
Type
Wall
Options
Splits
Color
Stripes
Tape
Length
A = HDPE
2 = 1/2"
C = Smooth/Smooth
4 = SCH 40
N = None
1 = 1 Way Single
A = Black
NN = None
A = Empty
1500
3 = 3/4"
5 = SCH 80
D = Lube Duct
2 = 2 Way Segmented
B = Blue
3A = Black Stripes
B = 1130 lbs. Polyester Tape
(Equals 1500 Feet)
5 = 1"
6 = SDR 11
3 = 3 Way Segmented
C = Brown
3B = Blue Stripes
C = 1250 lbs. Polyester Tape
6 = 1-1/4"
9 = SDR 13.5
4 = 4 Way Segmented
D = Buff
3C = Brown Stripes
D = 1500 lbs. Polyester Tape
9 = 1-1/2"
13 = SDR 15.5
5 = 2 Way Parallel
E = Gray
3D = Buff Stripes
E = 1800 lbs. Polyester Tape
13 = 2"
14 = SDR 17
6 = 3 Way Parallel
F = Green
3E = Gray Stripes
G = 200 lbs. Polyester Tape
14 = 2-1/2"
16 = SDR 21
7 = 4 Way Parallel
G = Lilac 3F = Green Stripes
J = 2500 lbs. Polyester Tape
15 = 3"
22 = SDR 7
12 = 2 Way Compart
H = Lt. Green
3G = Lilac Stripes
K = 400 lbs. Detect. Polyester Tape
16 = 4"
24 = SDR 9
13 = 3 Way Compart
J = Orange
3H = Lt. Green Stripes
T = 1250 lbs. Poly Metric Tape
17 = 4.75"
26 = SIDR 11.5
14 = 4 Way Compart
K = Red
3J = Orange Stripes
V = 1250 lbs. Detectable 22G
18 = 5"
27 = SIDR 11.5 True
L = Terra Cotta
3K = Red Stripes
Poly Tape
22 = 6"
29 = SIDR 15
M = White
3L = Terra Cotta Stripes
23 = 7"
34 = SIDR 7
N = Yellow
3M = White Stripes
24 = 8"
36 = SIDR 9
3N = Yellow Stripes
25 = 10"
37 = SIDR 9 True
26 = 12"
42 = TC-7A
27 = 14"
45 = True 11
28 = 16"
46 = True 9
END CAPS
UNIVERSAL
ALUMINUM
COUPLINGS
BARBED
COUPLINGS
INTERNAL COUPLINGS
