Carlon Multi-Gard PVC Product Description User Manual
Page 4
MULTI-GARD
®
PVC RACEWAY
www.carlonsales.com
PVC Multi-Cell Flexible Bends With Bell
Multi-Gard flexible bends use a patented design capable of a 4' minimum bend
radius and use the same coupling design as straight sections and fixed bends.
All bends are provided with engineered plastic innerducts to avoid rope cut-
through.
Part No.
Description
Pkg. Qty. Wt. ea.
M _ F _ 4 _ 4-cell Flexible Bend 1.19 I.D.
*
*
M _ _ _ N35 3-cell Flexible Bend 1.50 I.D.
*
*
Product
Pos. 1
Outerduct
Pos. 2
Pos. 3
Degree and Radius (R)
Pos. 4
Cells
Pos.5
Pos.6
M = Multi-Cell
X = Type C
F = Type 40
Flexible
B = 126" (Length) 4' x 90°
C = 192" (Length) 6' x 90°
4 = 4-Cell
3 = 3-Cell
_ = Standard
J = Jet
* Pkg. Qty. and Wt. ea.
Gross Automation (877) 268-3700 · www.carlonsales.com · [email protected]
