4 5
GRP CH BAND
L
ANT
MHz ACT RF AF
SQ BA
ADD
EQ
PUSH FOR MODE
ACT DIGITAL WIRELESS RECEIVER PARAMETER
ACT-818
GRP CH BAND
L
ANT
MHz ACT RF AF
SQ BA
ADD
EQ
ACT ACT
PUSH FOR MODE PUSH FOR MODE
ACT-828
PARAMETER DIGITAL WIRELESS RECEIVER C H 1 CH 2 DIGITAL WIRELESS RECEIVER
GRP CH BAND
L
ANT
MHz ACT RF AF
SQ BA
ADD
EQ
1 1
1 1
2 2 3 3
2 2 3 3 3 3
4 4
4 4 4 4
5 5
5 5 5 5
1 1
1 1
ACT-818
ACT-828
Front Antenna A/B Input Connector Access: Allows fitting of an optional FBC-71
rear-to-front antenna kit to enable front antenna placement.
Power Switch and Indicator: Powers the receiver on or off. When switch is turned
on, the red indicator illuminates and VFD panel will light up.
Receiver Display Screen: Color VFD (Vacuum Fluorescent Display).
ACT Button & IR Port: Press and release ACT button syncs the transmitter and
receiver frequency automatically.
Rotary Knob: Selects and sets the parameters.
1 1
2 2
3 3
4 4
5 5
Receiver Controls and Indicators
Front Panel
+8V DC BIAS ANTENNA B
BALANCED OUT CH2 BALANCED OUT CH1
LIFT LIFT
OUTPUT CH2 OUTPUT CH1
SPDIF OUT CH2 SPDIF OUT CH1
GND GND MIC MIC
LINE LINE
This connector can not be connected
to telecommunication networks.
REMOTE OUT IN (12~15V) DC INPUT +8V DC BIAS ANTENNA A
AC INPUT: 100~240V MADE IN TAIWAN
+8V DC BIAS +8V DC BIAS ANTENNA A ANTENNA B
This connector can not be connected
to telecommunication networks.
REMOTE OUT IN
MADE IN TAIWAN
(12~15V)
LIFT
OUTPUT
SPDIF OUT
GND MIC
LINE
BALANCED OUT
DC INPUT
6 6
6 6
7 7
7 7
8 8
8 8 8 8
11 11
11 11 11 11
15 15
16 16
6 6
6 6
10 10
10 10 10 10
12 12
12 12 12 12
13 13
13 13
14 14
14 14
9 9
9 9 9 9 15 15
ACT-818
ACT-828
Receiver Controls and Indicators
Rear Panel
6 6
7 7
8 8
9 9
10 10
11 11
12 12
Rack-Mount Brackets: Fits into a standard 19-inch rack case.
Optional MIPRO FBC-71 rear-to-front cables can be installed for front antenna
placement to improve reception quality.
Rear Antenna B Input Connector: The B antenna installs directly to this
connector and also provides power to an optional antenna booster (AT-70B) or
active antenna (AT-90W/AT-70W).
Lift/GND switch (CH2/CH1).
GND: Pin 1 of XLR connector is grounded;
LIFT: Pin 1 of XLR connector is not grounded. (GND = default value).
Balanced Audio Output Socket (CH2/CH1): 3 pin XLR type connector provides
balanced audio output signal same as microphone sensitivity level.
Mic/Line Switch (CH2/CH1): Controls analog balanced output & unbalanced
output level.
MIC level is microphone output level (0dB);
LINE level is auxiliary output.
Unbalanced Audio Output Jack (CH2/CH1): 6.3mm (1/4”) phone-jack type
connector provides unbalanced audio output signal.
Digital Output (CH2/CH1): SPDIF Digital Output
Wideband Digital Receivers Wideband Digital Receivers
