31
Figure 4.11
4) View live PIDs on the screen. Use the SCROLL button for more
PIDs if additional information is available on more than one page.
Figure 4.12
 The number “x” to the right of the screen indicates sequence
of the highlighted item.
5) Press the ENTER/Exit button to return to previous menu.
6) Select Previous Menu from the Read Codes screen, and press
ENTER/Exit button to return to previous menu
4.4 Viewing Freeze Frame Data
Freeze Frame Data allows the technician to view the vehicle‟s
operating parameters at the moment a DTC (Diagnostic Trouble Code)
is detected. For example, the parameters may include engine speed
(RPM), engine coolant temperature (ECT), or vehicle speed sensor
………………… View Data 1/3 .
Complete Data Set
Unit of Measure
Previous Menu
Live Data 6
DTC_CNT 0
FUELSYS1 0L
FUELSYS2 --
LOAD_PCT (%) 0.0
ETC(℃) -40
SHRTFT1 (%) 99.2
