SLD - Dual Input DC Modules
Model:
SLD-60-505-255
SLD-61-505-255
SLD-80-20-102
SLD-61-5-752
SLD-62-5-752
SLD-60-105-550
Input Rating:
Channel
A
B
A
B
A
B
A
B
A
B
A
B
Voltage (Volt)
+60V
+60V
+60V
-60V
+80V
+80V
+60V
-60V
-60V
-60V
+60V
+60V
Current (Ampere)
50A
5A
50A
5A
20A
20A
5A
5A
5A
5A
100A
5A
Power (VA)
250W
50W
250W
50W
100W
100W
75W
75W
75W
75W
500W
50W
Minimum Voltage
(Full Current)
0.4V @
50A
0.4V @
5A
0.4V @
50A
0.9V @
5A
0.4V @
20A
0.4V @
20A
0.4V @
5A
0.4V @
5A
0.4V @
5A
0.4V @
5A
0.4V @
100A
0.4V @
5A
CC Mode:
Range
0 - 5A
/ 50A
0 - 0.5A
/ 5A
0 - 5A
/ 50A
0 - 0.5A
/ 5A
0 - 2.0A
/ 20A
0 - 2.0A
/ 20A
0 - 0.5A
/ 5A
0 - 0.5A
/ 5A
0 - 0.5A
/ 5A
0 - 0.5A
/ 5A
0 - 10A
/ 100A
0 - 0.5A
/ 5A
Resolution
1.34 /
13.4mA
0.134 /
1.34mA
1.34 /
13.4mA
0.134 /
1.34mA
0.533 /
5.33mA
0.533 /
5.33mA
0.134 /
1.34mA
0.134 /
1.34mA
0.134 /
1.34mA
0.134 /
1.34mA
2.66 /
26.6mA
0.134 /
1.34mA
Accuracy
±0.2% of (Setting + Range)
CR Mode:
Range 1: (Ω)
(I>0.02% of rating)
1.2 -
4500
12 -
45000
1.2 -
4500
12 -
45000
4 -
15000
4 -
15000
12 -
45000
12 -
45000
12 -
45000
12 -
45000
0.6 -
2250
12 -
45000
Range 2: (Ω)
(I>0.2% of rating)
0.04-1.2
0.4-12
0.04-1.2
0.4-12
0.133-4
0.133-4
0.4-12
0.4-12
0.4-12
0.4-12
0.02-0.6
0.4-12
CV Mode
Range
0 – 60V
0 – (-60)V
0 – 60V
0 – (-60)V
0 – 60V
Resolution
16mV
21.3mV
16mV
Accuracy
±0.2% of (Setting + Range)
Short Mode
Resistance
8mΩ
0.08Ω
8mΩ
0.18Ω
0.02Ω
0.02Ω
0.02Ω
0.06Ω
0.06Ω
0.06Ω
4mΩ
0.08Ω
Current
50A
5A
50A
5A
20A
20A
5A
5A
5A
5A
100A
5 A
Dynamic Mode
T High / T Low
50µs to 9.999s
Slew Rate
(mA/µs)
4-200
40-2000
0.4-20
4-200
4-200
40-2000
0.4-20
4-200
1.6-80
16-800
1.6-80
16-800
0.4-20
4-200
0.4-20
4-200
0.4-20
4-200
0.4-20
4-200
8-400
80-4000
0.4-20
4-200
Resolution
(mA/µs)
0.8
8
0.08
0.8
0.8
8
0.08
0.8
0.32
3.2
0.32
3.2
0.08
0.8
0.08
0.8
0.08
0.8
0.08
0.8
1.6
16
0.08
0.8
Accuracy
±(10% +10µs)
4 1/2 DVM:
Range
15V / 60.00V
20V / 80V
15V / 60.00V
Resolution
0.001 V / 0.01 V
Accuracy
±0.05% of (Reading + Range)
4 1/2 DAM:
Range
15A / 50A
1.5A /
5A
15A / 50A
1.5A /
5A
2.0A /
20A
2.0A /
20A
1.5A /
5A
1.5A /
5A
1.5A /
5A
1.5A /
5A
10 /
100A
1.5A /
5A
Resolution
1mA /
10mA
0.1mA /
1mA
1mA /
10mA
0.1mA /
1mA
0.1mA /
1mA
0.1mA /
1mA
0.1mA /
1mA
0.1mA /
1mA
0.1mA /
1mA
0.1mA /
1mA
1 /
10mA
0.1mA /
1mA
Accuracy
±0.2% of (Reading + Range)
Load ON Voltage
Range
0.1-25V
Resolution
0.1V
Accuracy
1% of Setting +0.25V
Load OFF Voltage
Range
0-25V
Resolution
1mV
Accuracy
1% of Setting +0.25V
SL Series : Specifications
75 W–14.4 kW
