SLH - Standalone AC Loads
Model SLH-500-4-1200 SLH-500-6-1800 SLH-300-12-1200 SLH-300-12-1800 SLH-300-18-1800
Input Ratings
Power: 1200VA 1800VA 1200VA 1800VA 1800VA
Current: 4Arms 6Arms 12Arms 12Arms 18Arms
Voltage: 300Vrms / 500Vdc 300Vrms / 500Vdc 300Vrms 300Vrms 300Vrms
Frequency: DC, 40 - 70Hz (CC Mode) ; DC - 70Hz (CR Mode)
CC Mode
Range: 0-2 / 2-4A 0-3 / 3-6A 0-6 / 6-12A 0-6 / 6-12A 0-9 / 9-18A
Resolution: 0.5 / 1mA 0.75 / 1.5mA 1.5 / 3mA 1.5 / 3mA 2.25 / 4.5mA
Accuracy: ±0.5% of (setting + range)
Low Current: 0 - 0.2A 0 - 0.3A 0 - 0.6A 0 - 0.6A 0 - 0.9A
Accuracy: ±(0.5% of reading + 0.2% of range)
Maximum Peak Current: 8A 12A 24A 24A 18A
CR Mode
Range 1: (I>0.5% of rating) 50 - 200,000Ω 33.33 - 133,000Ω 20 - 80,000Ω 20 - 80,000Ω 13.3 - 53,333Ω
Range 2: (I>50% of rating) 12.5 - 50Ω 8.33 - 33.33Ω 5 - 20Ω 5 - 20Ω 3.33 - 13.33Ω
4 1/2 DVM
Range: 0-500V 0-500V 300V 300V 300V
Resolution: 0.1V 0.1V 0.1V 0.1V 0.1V
Accuracy: ±(0.5% of reading + 0.2% of range)
4 1/2 DAM
Range: 0-4A 0-6A 0-12A 0-12A 0-18A
Resolution: 1mA 1mA 1mA 1mA 1mA
Accuracy: ±(0.5% of reading + 2% of range) ; ±0.5% of (reading + range) @ 50/60Hz
4 1/2 Watt Meter
Range: 0-1200W 0-1800W 0-1200W 0-1800W 0-1800W
Resolution: 0.1W
Accuracy: ± (0.5% of reading)±3W
VA / Power Meter: Vrms × Arms
Weight 18.5kgs/40.7lbs 21.5kgs/47.3lbs 18.5kgs/40.7lbs 21.5kgs/47.3lbs 21.5kgs/47.3lbs
SLM - AC Modules
Model SLM-60-20-300 SLM-150-8-300 SLM-300-4-300 SLM-500-1-300
Input Ratings
Power: 300VA 300VA 300VA 300VA
Current: 20Arms 8Arms 4Arms 1Arms
Voltage: 60Vrms 150Vrms 300Vrms 300Vrms / 500Vdc
Frequency: DC, 40 - 70Hz (CC Mode) ; DC - 70Hz (CR Mode)
CC Mode
Range: 0-10 / 10-20A 0-4 / 4-8A 0-2 / 2-4A 0-0.5 / 0.5-1A
Resolution: 2.5 / 5mA 1 / 2mA 0.5 / 1mA 0.125 / 0.25mA
Accuracy: ±0.5% of (setting + range)
Low Current: 0 - 1A 0 - 0.4A 0 - 0.2A 0 - 0.05A
Accuracy: ±2% of (setting + range)
Maxium Peak Current: 40A 16A 8A 2A
CR Mode (1)
Range 1: (I>0.5% of rating) 1.2-4,800Ω 7.5-30,000Ω 30 - 120,000Ω 200 - 800000Ω
Range 2: (I>50% of rating) 0.3 - 1.2Ω 1.875 - 7.5Ω 7.5 - 30Ω 50 - 200Ω
4 1/2 DVM
Range: 60V 150V 300V 500V
Resolution: 0.01V 0.01V 0.1V 0.1V
Accuracy: ±(0.5% of reading + 0.2% of range)
4 1/2 DAM
Range: 20A 8A 4A 1A
Resolution: 0.01A 0.001A 0.001A 0.001A
Accuracy: ±(0.5% of reading + 2% of range); ±0.5% of (reading + range) @ 50/60Hz
4 1/2 Watt Meter
Range: 300W
Resolution: 0.1W
Accuracy: ±(0.5% of reading)±3W
VA / Power Meter: Vrms × Arms
Weight 3.5kgs/7.7lbs
SL Series : Specifications 75 W–14.4 kW
