TDS 600 Series
Characteristics
Continued Altitude –
Operating: 15,000 ft. (hard disk not used),
10,000 ft. (hard disk in use). Non-operating:
40,000 ft.
Electromagnetic Compatibility –
Meets or
exceeds EN55011 Class A Radiated and
Conducted Emissions; EN 50081-1;
EN60555-2 Power Harmonics; FCC 47 CFR,
Part 15. Subpart B, Class A; Australian EMC
Framework; EN 50082-1
Safety –
UL 3111-1, CSA-22.2 No. 1010.1
PHYSICAL CHARACTERISTICS
Dimensions mm in.
Height with feet 193 7.6
Height without feet 178 7
Width with handle 445 17.5
Depth with front 434 17.1
cover installed
Weight kg lbs.
Net approximately 14.1 31
Shipping Weight 24.0 53
approximately
5/99 HB/XBS 55W-10066-7
